The IEC/UL/CSA 60320-3 Interpower Appliance Coupler Sheet is an invaluable reference tool for customers. Accurately ordering connectors, inlets, plug connectors, and outlets is crucial with ever-lagging supply chains.
Below is the latest Appliance Coupler Sheet. The chart is organized into components that mate with each other such as the IEC 60320 Sheet E plug connector mating with the Sheet F Outlet, and the C13 connector mating with the C14 inlet. The C13 and C14 are the two most common IEC 60320 components used at Interpower. The sheet displays multiple component pairings to assist customers in ordering the exact products they need.
Further questions? Interpower’s expert customer service team is available Monday through Friday from 7 a.m. to 6 p.m. CST. Or visit our Web site at https://www.interpower.com/ic/.
IEC/UL/CSA 60320-3 Coupler Sheet
Appliance Couplers |
Connectors |
|
Inlets |
|
Plug Connectors |
|
Outlets |
C1 (non-rewireable only)
|
Class II Cold
|
C2
|
0.2A Family
|
These couplers are not in the standard.
|
C5 (non-rewireable only)
|
Class I Cold
|
C6
|
2.5A Int'l/ 7A or 2.5A North American Family
|
SHEET A (non-rewireable only)
|
Class I
|
SHEET B
|
C7 (non-rewireable only)
|
Class II Cold
|
C8
|
SHEET C (non-rewireable only)
|
Class II
|
SHEET D
|
C9 (non-rewireable only)
|
Class II Cold
|
C10
|
6A Family
|
These couplers are not in the standard.
|
C13
|
Class I Cold
|
C14
|
10A Int'l/ 15A North American Family
|
SHEET E
|
Class I
|
SHEET F
|
C15
|
Class I Hot
|
C16
|
These couplers are not in the standard.
|
C15A
|
Class I Very Hot
|
C16A
|
These couplers are not in the standard.
|
C17 (non-rewireable only)
|
Class II Cold
|
C18
|
SHEET G (non-rewireable only)
|
Class II
|
SHEET H
|
C19
|
Class I Cold
|
C20
|
16A Int'l/ 20A North American Family
|
SHEET I
|
Class I
|
SHEET J
|
C21
|
Class I Very Hot
|
C22
|
These couplers are not in the standard.
|
C23 (non-rewireable only)
|
Class II Cold
|
C24
|
SHEET K (non-rewireable only)
|
Class II
|
SHEET L
|
These couplers are for AC only, with a rated voltage not exceeding 250VAC and not exceeding the rated currents listed above for 50Hz or 60Hz power.
|
